ERK3 (Phospho-Ser189) Colorimetric Cell-Based ELISA Kit
- SKU:
- CBCAB01422
- Product Type:
- ELISA Kit
- ELISA Type:
- Cell Based Phospho Specific
- Research Area:
- Cell Cycle
- Reactivity:
- Human
- Mouse
- Rat
- Detection Method:
- Colorimetric
Description
ERK3 (Phospho-Ser189)Colorimetric Cell-Based ELISA Kit
The ERK3 Phospho-Ser189 Colorimetric Cell-Based ELISA Kit is specifically designed for the precise detection of phosphorylated ERK3 protein levels in cell lysates. This kit boasts high sensitivity and specificity, allowing for accurate and reproducible results, making it an invaluable tool for various research applications.Phosphorylated ERK3, particularly at the Serine 189 site, is a key signaling protein involved in various cellular processes, including cell growth, proliferation, and differentiation. Dysregulation of ERK3 phosphorylation has been associated with several diseases, including cancer, inflammatory disorders, and neurodegenerative diseases, making it a crucial biomarker for studying these conditions and potentially developing targeted therapies.
Overall, the ERK3 Phospho-Ser189 Colorimetric Cell-Based ELISA Kit provides researchers with a reliable and efficient method for analyzing phosphorylated ERK3 levels, advancing our understanding of cellular signaling pathways and potential therapeutic targets for various diseases.
| Product Name: | ERK3 (Phospho-Ser189) Colorimetric Cell-Based ELISA |
| Product Code: | CBCAB01422 |
| ELISA Type: | Cell-Based |
| Target: | ERK3 (Phospho-Ser189) |
| Reactivity: | Human, Mouse, Rat |
| Dynamic Range: | > 5000 Cells |
| Detection Method: | Colorimetric 450 nm |
| Format: | 2 x 96-Well Microplates |
The ERK3 (Phospho-Ser189) Colorimetric Cell-Based ELISA Kit is a convenient, lysate-free, high throughput and sensitive assay kit that can detect ERK3 protein phosphorylation and expression profile in cells. The kit can be used for measuring the relative amounts of phosphorylated ERK3 in cultured cells as well as screening for the effects that various treatments, inhibitors (ie. siRNA or chemicals), or activators have on ERK3 phosphorylation.
Qualitative determination of ERK3 (Phospho-Ser189) concentration is achieved by an indirect ELISA format. In essence, ERK3 (Phospho-Ser189) is captured by ERK3 (Phospho-Ser189)-specific primary (1ø) antibodies while the HRP-conjugated secondary (2ø) antibodies bind the Fc region of the 1ø antibody. Through this binding, the HRP enzyme conjugated to the 2ø antibody can catalyze a colorimetric reaction upon substrate addition. Due to the qualitative nature of the Cell-Based ELISA, multiple normalization methods are needed:
| 1. | A monoclonal antibody specific for human GAPDH is included to serve as an internal positive control in normalizing the target absorbance values. |
| 2. | Following the colorimetric measurement of HRP activity via substrate addition, the Crystal Violet whole-cell staining method may be used to determine cell density. After staining, the results can be analysed by normalizing the absorbance values to cell amounts, by which the plating difference can be adjusted. |
| Database Information: | Gene ID: 5597, UniProt ID: Q16659, OMIM: 602904, Unigene: Hs.411847 |
| Gene Symbol: | MAPK6 |
| Sub Type: | Phospho |
| UniProt Protein Function: | ERK3: a protein kinase of the MAPK family. Plays a critical role in the regulation of cell growth and differentiation. Localized in the nucleus, and has been reported to be activated in fibroblasts upon treatment with serum or phorbol esters. |
| UniProt Protein Details: | Protein type:Protein kinase, Ser/Thr (non-receptor); Protein kinase, CMGC; Kinase, protein; EC 2.7.11.24; CMGC group; MAPK family; MAPK/ERK subfamily; ERK subfamily Chromosomal Location of Human Ortholog: 15q21 Cellular Component: cytoplasm; cytosol; nucleoplasm; nucleus Molecular Function:MAP kinase activity; protein binding; protein serine/threonine kinase activity Biological Process: protein amino acid phosphorylation; signal transduction |
| NCBI Summary: | The protein encoded by this gene is a member of the Ser/Thr protein kinase family, and is most closely related to mitogen-activated protein kinases (MAP kinases). MAP kinases also known as extracellular signal-regulated kinases (ERKs), are activated through protein phosphorylation cascades and act as integration points for multiple biochemical signals. This kinase is localized in the nucleus, and has been reported to be activated in fibroblasts upon treatment with serum or phorbol esters. [provided by RefSeq, Jul 2008] |
| UniProt Code: | Q16659 |
| NCBI GenInfo Identifier: | 2499596 |
| NCBI Gene ID: | 5597 |
| NCBI Accession: | Q16659.1 |
| UniProt Secondary Accession: | Q16659,Q68DH4, Q8IYN8, B2R945, B5BU65, |
| UniProt Related Accession: | Q16659 |
| Molecular Weight: | 82,681 Da |
| NCBI Full Name: | Mitogen-activated protein kinase 6 |
| NCBI Synonym Full Names: | mitogen-activated protein kinase 6 |
| NCBI Official Symbol: | MAPK6 |
| NCBI Official Synonym Symbols: | ERK3; PRKM6; p97MAPK; HsT17250 |
| NCBI Protein Information: | mitogen-activated protein kinase 6 |
| UniProt Protein Name: | Mitogen-activated protein kinase 6 |
| UniProt Synonym Protein Names: | Extracellular signal-regulated kinase 3; ERK-3; MAP kinase isoform p97; p97-MAPK |
| UniProt Gene Name: | MAPK6 |
| UniProt Entry Name: | MK06_HUMAN |
| Component | Quantity |
| 96-Well Cell Culture Clear-Bottom Microplate | 2 plates |
| 10X TBS | 24 mL |
| Quenching Buffer | 24 mL |
| Blocking Buffer | 50 mL |
| 15X Wash Buffer | 50 mL |
| Primary Antibody Diluent | 12 mL |
| 100x Anti-Phospho Target Antibody | 60 µL |
| 100x Anti-Target Antibody | 60 µL |
| Anti-GAPDH Antibody | 60 µL |
| HRP-Conjugated Anti-Rabbit IgG Antibody | 12 mL |
| HRP-Conjugated Anti-Mouse IgG Antibody | 12 mL |
| SDS Solution | 12 mL |
| Stop Solution | 24 mL |
| Ready-to-Use Substrate | 12 mL |
| Crystal Violet Solution | 12 mL |
| Adhesive Plate Seals | 2 seals |
The following materials and/or equipment are NOT provided in this kit but are necessary to successfully conduct the experiment:
- Microplate reader able to measure absorbance at 450 nm and/or 595 nm for Crystal Violet Cell Staining (Optional)
- Micropipettes with capability of measuring volumes ranging from 1 µL to 1 ml
- 37% formaldehyde (Sigma Cat# F-8775) or formaldehyde from other sources
- Squirt bottle, manifold dispenser, multichannel pipette reservoir or automated microplate washer
- Graph paper or computer software capable of generating or displaying logarithmic functions
- Absorbent papers or vacuum aspirator
- Test tubes or microfuge tubes capable of storing ≥1 ml
- Poly-L-Lysine (Sigma Cat# P4832 for suspension cells)
- Orbital shaker (optional)
- Deionized or sterile water
*Note: Protocols are specific to each batch/lot. For the correct instructions please follow the protocol included in your kit.
| Step | Procedure |
| 1. | Seed 200 µL of 20,000 adherent cells in culture medium in each well of a 96-well plate. The plates included in the kit are sterile and treated for cell culture. For suspension cells and loosely attached cells, coat the plates with 100 µL of 10 µg/ml Poly-L-Lysine (not included) to each well of a 96-well plate for 30 minutes at 37 °C prior to adding cells. |
| 2. | Incubate the cells for overnight at 37 °C, 5% CO2. |
| 3. | Treat the cells as desired. |
| 4. | Remove the cell culture medium and rinse with 200 µL of 1x TBS, twice. |
| 5. | Fix the cells by incubating with 100 µL of Fixing Solution for 20 minutes at room temperature. The 4% formaldehyde is used for adherent cells and 8% formaldehyde is used for suspension cells and loosely attached cells. |
| 6. | Remove the Fixing Solution and wash the plate 3 times with 200 µL 1x Wash Buffer for five minutes each time with gentle shaking on the orbital shaker. The plate can be stored at 4 °C for a week. |
| 7. | Add 100 µL of Quenching Buffer and incubate for 20 minutes at room temperature. |
| 8. | Wash the plate 3 times with 1x Wash Buffer for 5 minutes each time. |
| 9. | Add 200 µL of Blocking Buffer and incubate for 1 hour at room temperature. |
| 10. | Wash 3 times with 200 µL of 1x Wash Buffer for 5 minutes each time. |
| 11. | Add 50 µL of 1x primary antibodies Anti-ERK3 (Phospho-Ser189) Antibody, Anti-ERK3 Antibody and/or Anti-GAPDH Antibody) to the corresponding wells, cover with Parafilm and incubate for 16 hours (overnight) at 4 °C. If the target expression is known to be high, incubate for 2 hours at room temperature. |
| 12. | Wash 3 times with 200 µL of 1x Wash Buffer for 5 minutes each time. |
| 13. | Add 50 µL of 1x secondary antibodies (HRP-Conjugated AntiRabbit IgG Antibody or HRP-Conjugated Anti-Mouse IgG Antibody) to corresponding wells and incubate for 1.5 hours at room temperature. |
| 14. | Wash 3 times with 200 µL of 1x Wash Buffer for 5 minutes each time. |
| 15. | Add 50 µL of Ready-to-Use Substrate to each well and incubate for 30 minutes at room temperature in the dark. |
| 16. | Add 50 µL of Stop Solution to each well and read OD at 450 nm immediately using the microplate reader. |
(Additional Crystal Violet staining may be performed if desired – details of this may be found in the kit technical manual.)
