Cullin 1 Colorimetric Cell-Based ELISA Kit

Product Name:	Cullin 1 Colorimetric Cell-Based ELISA
Product Code:	CBCAB00605
ELISA Type:	Cell-Based
Target:	Cullin 1
Reactivity:	Human, Mouse
Dynamic Range:	> 5000 Cells
Detection Method:	Colorimetric 450 nmStorage/Stability:4°C/6 Months
Format:	96-Well Microplate

The Cullin 1 Colorimetric Cell-Based ELISA Kit is a convenient, lysate-free, high throughput and sensitive assay kit that can detect Cullin 1 protein expression profile in cells. The kit can be used for measuring the relative amounts of Cullin 1 in cultured cells as well as screening for the effects that various treatments, inhibitors (ie siRNA or chemicals), or activators have on Cullin 1.

Qualitative determination of Cullin 1 concentration is achieved by an indirect ELISA format. In essence, Cullin 1 is captured by Cullin 1-specific primary antibodies while the HRP-conjugated secondary antibodies bind the Fc region of the primary antibody. Through this binding, the HRP enzyme conjugated to the secondary antibody can catalyze a colorimetric reaction upon substrate addition. Due to the qualitative nature of the Cell-Based ELISA, multiple normalization methods are needed:

1.	A monoclonal antibody specific for human GAPDH is included to serve as an internal positive control in normalizing the target absorbance values.
2.	Following the colorimetric measurement of HRP activity via substrate addition, the Crystal Violet whole-cell staining method may be used to determine cell density. After staining, the results can be analysed by normalizing the absorbance values to cell amounts, by which the plating difference can be adjusted.

Database Information:	Gene ID: 8454, UniProt ID: Q13616, OMIM: 603134, Unigene: Hs.146806
Gene Symbol:	CUL1
Sub Type:	None

UniProt Protein Function:	CUL1: a core scaffolding component of multiple cullin-RING-based SCF (SKP1- CUL1-F-box protein) E3 ubiquitin-protein ligase complexes, which mediate the ubiquitination of proteins involved in cell cycle progression, signal transduction and transcription. The cullin subunit serves as a rigid scaffold of SCF complexes. May contribute to catalysis through positioning of the substrate and the ubiquitin-conjugating enzyme. The E3 ubiquitin-protein ligase activity of the complex depends on the neddylation of the cullin subunit. Interacts with multiple F-box proteins in SCF complexes, directing the ubiquitination of many substrates. These F-box proteins and associated substrates include: BTRC and FBXW11 bind CTNNB1 and participate in Wnt signaling; FBXW11 bind phosphorylated NFKBIA; BTRC binds NFKBIB, NFKBIE, ATF4, SMAD3, SMAD4, CDC25A, FBXO5 and probably NFKB2; SKP2 binds phosphorylated p27kip and is involved in regulation of G1/S transition; SKP2 binds ORC1, CDT1, RBL2, ELF4, CDKN1A, RAG2, FOXO1A, and probably MYC and TAL1; FBXW7 binds cyclin E, NOTCH1 released notch intracellular domain (NICD), and probably PSEN1; FBXW2 binds GCM1; FBXO32 binds MYOD1; FBXO7 binds BIRC2 and DLGAP5; FBXO33 binds YBX1; and Cyclin F binds CP110. Interacts with CHEK2, mediating its ubiquitination and regulating its function. Belongs to the cullin family.
UniProt Protein Details:	Protein type:Ubiquitin conjugating system; Cell cycle regulation Chromosomal Location of Human Ortholog: 7q36.1 Cellular Component: nucleoplasm; cullin-RING ubiquitin ligase complex; SCF ubiquitin ligase complex; cytosol Molecular Function:protein binding; ubiquitin protein ligase binding Biological Process: protein monoubiquitination; positive regulation of ubiquitin-protein ligase activity during mitotic cell cycle; circadian rhythm; SCF-dependent proteasomal ubiquitin-dependent protein catabolic process; Notch signaling pathway; viral reproduction; protein ubiquitination; negative regulation of cell proliferation; cell proliferation; organ morphogenesis; regulation of ubiquitin-protein ligase activity during mitotic cell cycle; anaphase-promoting complex-dependent proteasomal ubiquitin-dependent protein catabolic process; mitotic cell cycle; cell cycle arrest; G2/M transition of mitotic cell cycle; G1/S transition of mitotic cell cycle
UniProt Code:	Q13616
NCBI GenInfo Identifier:	19863257
NCBI Gene ID:	8454
NCBI Accession:	Q13616.2
UniProt Secondary Accession:	Q13616,O60719, Q08AL6, Q8IYW1, D3DWG3,
UniProt Related Accession:	Q13616
Molecular Weight:	89,679 Da
NCBI Full Name:	Cullin-1
NCBI Synonym Full Names:	cullin 1
NCBI Official Symbol:	CUL1
NCBI Protein Information:	cullin-1; CUL-1
UniProt Protein Name:	Cullin-1
Protein Family:	Cullin
UniProt Gene Name:	CUL1
UniProt Entry Name:	CUL1_HUMAN

Component	Quantity
96-Well Cell Culture Clear-Bottom Microplate	2 plates
10X TBS	24 mL
Quenching Buffer	24 mL
Blocking Buffer	50 mL
15X Wash Buffer	50 mL
Primary Antibody Diluent	12 mL
100x Anti-Phospho Target Antibody	60 µL
100x Anti-Target Antibody	60 µL
Anti-GAPDH Antibody	60 µL
HRP-Conjugated Anti-Rabbit IgG Antibody	12 mL
HRP-Conjugated Anti-Mouse IgG Antibody	12 mL
SDS Solution	12 mL
Stop Solution	24 mL
Ready-to-Use Substrate	12 mL
Crystal Violet Solution	12 mL
Adhesive Plate Seals	2 seals

The following materials and/or equipment are NOT provided in this kit but are necessary to successfully conduct the experiment:

Microplate reader able to measure absorbance at 450 nm and/or 595 nm for Crystal Violet Cell Staining (Optional)
Micropipettes with capability of measuring volumes ranging from 1 µL to 1 ml
37% formaldehyde (Sigma Cat# F-8775) or formaldehyde from other sources
Squirt bottle, manifold dispenser, multichannel pipette reservoir or automated microplate washer
Graph paper or computer software capable of generating or displaying logarithmic functions
Absorbent papers or vacuum aspirator
Test tubes or microfuge tubes capable of storing ≥1 ml
Poly-L-Lysine (Sigma Cat# P4832 for suspension cells)
Orbital shaker (optional)
Deionized or sterile water

*Note: Protocols are specific to each batch/lot. For the correct instructions please follow the protocol included in your kit.

Step	Procedure
1.	Seed 200 µL of 20,000 adherent cells in culture medium in each well of a 96-well plate. The plates included in the kit are sterile and treated for cell culture. For suspension cells and loosely attached cells, coat the plates with 100 µL of 10 µg/ml Poly-L-Lysine (not included) to each well of a 96-well plate for 30 minutes at 37°C prior to adding cells.
2.	Incubate the cells for overnight at 37°C, 5% CO2.
3.	Treat the cells as desired.
4.	Remove the cell culture medium and rinse with 200 µL of 1x TBS, twice.
5.	Fix the cells by incubating with 100 µL of Fixing Solution for 20 minutes at room temperature. The 4% formaldehyde is used for adherent cells and 8% formaldehyde is used for suspension cells and loosely attached cells.
6.	Remove the Fixing Solution and wash the plate 3 times with 200 µL 1x Wash Buffer for five minutes each time with gentle shaking on the orbital shaker. The plate can be stored at 4°C for a week.
7.	Add 100 µL of Quenching Buffer and incubate for 20 minutes at room temperature.
8.	Wash the plate 3 times with 1x Wash Buffer for 5 minutes each time.
9.	Add 200 µL of Blocking Buffer and incubate for 1 hour at room temperature.
10.	Wash 3 times with 200 µL of 1x Wash Buffer for 5 minutes each time.
11.	Add 50 µL of 1x primary antibodies (Anti-Cullin 1 Antibody and/or Anti-GAPDH Antibody) to the corresponding wells, cover with Parafilm and incubate for 16 hours (overnight) at 4°C. If the target expression is known to be high, incubate for 2 hours at room temperature.
12.	Wash 3 times with 200 µL of 1x Wash Buffer for 5 minutes each time.
13.	Add 50 µL of 1x secondary antibodies (HRP-Conjugated AntiRabbit IgG Antibody or HRP-Conjugated Anti-Mouse IgG Antibody) to corresponding wells and incubate for 1.5 hours at room temperature.
14.	Wash 3 times with 200 µL of 1x Wash Buffer for 5 minutes each time.
15.	Add 50 µL of Ready-to-Use Substrate to each well and incubate for 30 minutes at room temperature in the dark.
16.	Add 50 µL of Stop Solution to each well and read OD at 450 nm immediately using the microplate reader.

(Additional Crystal Violet staining may be performed if desired – details of this may be found in the kit technical manual.)
